Photovoltaic off-grid connection hybrid inverter Outdoor solar energy storage device

EAN:
SKU: PSID0600. Photovoltaic grid-connected micro-inverter
PV Max Input Power (W) :350 x 2
PV Max Input Voltage (V):60
Start-up Voltage (V):16
MPPT Voltage Range (V):30~55
Max Input Current (A):14A x 2
Number of MPP Trackers:2

AC Output
Rated Output Power (W):600
Nominal Output Current (A):2.6
Nominal Grid Voltage (V):230(single-phase)
Grid Voltage Range (V):180~264VAC
Nominal Grid Frequency (Hz):50Hz/60Hz
Max.Total Harmonic Distortion:<3%(rated power)
Power Factor:>0.99
Max Parallel:8pcs
Anti-islanding Protection:Yes
AC Short Circuit Protection:Yes

System
Max. Efficiency:96.70%
Protection Class:CLASS Ⅰ
Protection Level:IP67
Cooling Method:Natural Cooling
Monitoring:WIFI
Operating Temperature Range (℃):-30 ~ +60
Manufacturer's Warranty:2 Years

on-product information
Dimensions: 225mm 225mm 37mm
Weight: 2.8 kg

PRODUCT FEATURES
Low photovoltaic input voltage,
high and low voltage isolated, safe to use.
Built-in MPPT, DSP control,
DC to AC peakefficiency up to 96.7%.
Small and light-weighted, easy to install, IP67 class protection.
WIFI Remote monitoring.
Max 8pcs in parallel.
